UBNT AirFiber AF-24HD, 2Gbps + Backhaul, 24GHz (price per piece)
UBNT AirFiber AF-24HD, 2Gbps + Backhaul, 24GHz (price per piece)PRODUCT DESCRIPTION: The Ubiquiti airFiber AF-24-HD radio is designed for 24 GHz free bandwidth up to 2 Gbps at 256QAM maximum modulation .The AirFiber is equipped with 2 independent parabolic 2x2 MIMO antennas with different gains, helping to use the link over a longer distance than conventional single antenna systems. The connection can be operated in 2 modes: FDD ( Frequency Division Duplex ) and HDD ( Hybrid Division Duplex ), and thanks to these modes, they achieve high speed and spectral efficiency. The HDD system offers low latency of FDD systems and the spectral efficiency of TDD systems. For trouble-free monitoring and setup, Ethernet ports are provided in Drive 2 , one for management only and one for data + management. Wireless features: Sensitivity [dBm]: -87EIRP [dBm]: 33 (FCC / IC), 20 (CE)Frequency range [MHz]: 24050 - 24250Isolation between connectors [dB]: 28Maximum Modulation: 256QAMPolarization: VHPre-Ratio [dB]: 70Channel Width [MHz]: 100Baud rate - 24GHz [Mb / s]: 1024Encryption: WPA2 AESVyza?. azimuth angle (-6dB) [ ]: 3.5Vyza?. angle in elevation plane (-6dB) [ ]: 3.5Antenna gain [dBi]: Tx = 33, Rx = 40Physical characteristics Wind resistance [km / h]: 200Radom: Yes Designed for mast of diameter [mm]: 30 to 100Operating temperature [ C]: -40 to 55Weight [g]: 17300Depth [mm]: 370Width [mm]: 593Height [mm]: 768Connectors and interfaces LAN Speed: (1) 10/100 / 1000Mbps + (1) 10 / 100Mbps (management)GPS module: Yes Other: RJ-12 - measuring tone port Power supply Max. power consumption [W]: 50Power over PoE: 42 .. 58V DCSoftware Operating system: airOSF Default IP Address: 192.168.1.20Default Name and Password: ubnt / ubnt
